|Place of Origin:||Shijiazhuang Hebei China|
|Brand Name:||ALLIN Solar Power System|
|Certification:||CE , SGS, ISO9001|
|Minimum Order Quantity:||1-2|
|Price:||30-5000$/Set,Price needs to be negotiated|
|Packaging Details:||1pcs/pack,6pcs/pack, 12pcs/pack,Can be customized|
|Payment Terms:||L/C, D/A, D/P, T/T, Western Union, MoneyGram|
|Name:||5000W Output 1200A Battery Commercial Off Grid Solar Power System With 12V40A Controller||System Type:||Off Grid|
|Model:||AY-MS09-5000W||Solar Panel Material:||Monocrystalline Silicon|
|Solar Panel Power:||1200~3000W||Battery Capacity:||800~1600A|
|Battery Voltage:||12V||Output Power:||5000W|
|Output Frequency:||50Hz||Output Voltage:||5V12V110/220V|
1200A Off Grid Solar Power System,
5000W Off Grid Solar Power System,
40A Commercial Off Grid Solar Systems
On the one hand, fossil fuel reserves are limited and are facing the danger of exhaustion.On the other hand, burning fuels will exhaust CO2 and sulfur oxides, which will lead to the greenhouse effect and acid rain and worsen the earth's environment.Solar power generation uses the electronic properties of solar energy and semiconductor materials to generate electricity.What are the applications of solar power systems?
User solar power supply :(1) small power supply ranging from 10-100W, used in remote areas without electricity, such as plateau, island, pastoral areas, border posts and other military and civilian life electricity, such as lighting, TV, radio recorder, etc.;(2) 3-5KW household roof grid-connected power generation system;(3) Photovoltaic water pump: solve the drinking and irrigation of deep water Wells in areas without electricity.
Oil offshore and ship emergency power supply
Home yard lights, street lights, camping lights, hiking lights and so on
Farms generate electricity, cars and electric cars charge, and so on
The solar power generation system is composed of a solar battery group, a solar controller and a battery (group).If you want to make the solar power system output power for AC 220V or 110V, also need to configure the inverter.
|Solar Panel (W)||Battery (A)||Host Machine (W)|
(1) Output voltage (V):2USB 5V, 3DC 12V, 2AC 110V or 220V
(2) Charging time (H):According to local illumination time and solar radiation intensity(about 8-10H)
(3) Discharging time (H):According to output power(about 6-8H)
(4) Circuit protection :Overload, Short-circuit, Reverse polarity, High/low Battery voltage
(5) Operating temperature (℃):-25℃~55℃
The solar panel outputs direct current in the light.
The controller stored the direct current in the battery, or directly supplied to terminal load after being processed by inverter.
The controller, inverter and so on are located in the main machine.
|Product Configuration Instructions|
1200~3000W Solar panels
|Monocrystalline silicon material||1 Group|
(1)12V40A solar energy special controller, PMW intelligent, can prevent the battery over charge and discharge, effectively protect the battery.
(2)12V 5000W solar positive wave inverter, the output is equal to the mains power, belongs to the highest level of waveform.
(3) AC Voltmeter,DC Voltmeter, AC Output socket ,LED Socket,USB Socket, PV input socket, etc.
|3||PV cables||Dedicated||1 Group|
|4||Connection fittings||Dedicated||1 Set|
|5||Panel bracket||Dedicated||1 Set|
|6||5W LED lights and wires||Wire length 6 meters, straight socket.||2 Sets|
|7||Battery (outside of the host)||
Colloid maintenance-free solar battery.
800A battery ( 200A*4PS).
1200A battery (200A*6PS)
1600A battery (200*8PS)
Tips: The home solar power system 5000W can be used for loads with 220V currents less than 22.7A.
