96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor

Basic Information
Place of Origin: Shijiazhuang Hebei China
Certification: CE , SGS, ISO9001
Model Number: AY-09-380W
Minimum Order Quantity: 1-200sets
Price: 30-5000$/Set,Price needs to be negotiated
Packaging Details: 1pcs/pack,6pcs/pack, 12pcs/pack,Can be customized
Delivery Time: 3-25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 10000Sets/days
Detail Information
Product Name: 96 Cell Mono 500w Solar Panel Material: Monocrystalline Silicon
Application: Outdoor,Home, Camping Size: 1997x992x35mm
Frame: Anodized Aluminium Alloy Warranty: 25 Years Output Power Guarantee
Cell Arrange: 144(6x24) Surface Glass: 3.2mm High Transmittance Coated Tempered Glass
Solar Cell: Mono PERC Half Cut Weight: 22kg
Output Voltage (v): 1000V/1500V DC(IEC) Load Power (w): 500W
High Light:

96 cell mono 500w solar panel


48.35v 500w solar panel


outdoor mono solar panel 500 watt

Product Description

Wholesale high quality high efficiency 96 cell mono 500w solar panel



1. Description

Maximum power at STC(Pmax) 500W
Optimum operating voltage(Vmp) 48.35V
Optimum operating current(Imp) 9.93A
Open-circuit voltage(Voc) 58.89V
Short-circuit current(Isc) 10.4A
Short-circuit current temperature coefficient (0.065±0.015)%/℃
Open-circuit voltage temperature coefficient -(80±10)mV/℃-(80±10)mV/℃
Peak power temperature coefficient -(0.5±0.05)%/℃
NOCT (Air 20℃; Sun 0.8kW/m wind 1m/s) 47±2℃
Operating temperature -40℃ to 85℃
Maximum system voltage 600V DC
Power tolerance ±3%
STC lrradiance 1000W/m², Module temperature 25℃, AM=1.5
Size(mm) 1960*1310*40/45
Weight(kg) 26

Solar Panel Advantage:
1)One Phone remote control ALL solar system, water pump, street lights, CCTV.
2)Troubleshoot and reduce maintenance costs
3)Develop your brande APP to enhance competitiveness

We are China's Largest Authorized Distributor of Brand Solar Panels: LONGI SOLAR, CANADIAN SOLAR, TRINA SOLAR, JA SOLAR...
We Supplying Full Range of JA Solar Panels.
In allinsolar, you can find the best price tier 1 solar panels, so don't waste time and safely buy the best products to start your business on allinsolar.

2. Parameter Datas


Mono Half Cell Monocrystalline 500w Photovoltaic Solarpanel Cell For Home Roof



Product Name Mono Solar Panels
Panel Size 1956*1310*40mm
Cells 144(6*24)
Weight 17 kg
Coated tempered glass
Packing 66 pcs/pallet
Loading in 40'FCL 726 pcs



STC Parameter
Max Out Put(Pmax/W) 370 375 380 385 390
VOC(V) 48.35 48.75 49.06 49.35 49.65
ISC(A) 9.79 9.86 9.93 10 10.07
Vmp(V) 39.88 40.11 40.34 40.57 40.8
Imp(A) 9.28 9.35 9.42 9.49 9.56
conversion efficiency(%) 18.36 18.93 19.18 19.43 19.69
Work Temperature -40℃-85℃
Max system voltage 1000/1500V




96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor 0

96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor 1


3.  Advantages


High component conversion efficiency, advanced manufacturing technology

Five main grid line solar cells are used to reduce power loss

The hidden crack and other invisible microscopic crack defects of solar cells are strictly controlled

Adopt advanced low reflection high transmittance glass and advanced battery technology, in the evening, cloudy, cloudy and other low light environment can also play a good performance.

Factory Direct High Efficiency All Black Solar Panel Monocrystalline 400W Mono Solar Panels Cell : A grade solar cells
A Wide Range of Products:Mono-crystalline solar panel and poly(multi)-crystalline solar panel(depending on configurations)
High Reliability:Guaranteed mechanical resistance to severe weather conditions for reliable power output.Compliant with IEC 61215 and IEC61730.Certified by TUV,CE,ISO and etc.
Tight Tolerance:Guaranteed positive tol erance from 0-3% ebsures power ♦output reliability.
Traceability:We provide flash report and embedded bar code ID for each module for complete traceability
A Wide Range of Applications: Independent systems(household,powder supplies for remote areas, remote systems, ete.)and grid-connected photovoltaic power stations(residential,commercial, industrial power supply systems)
Warranty:10-year limited product warranty and 25-year limited power guarantee


96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor 2



4. Application


Monocrystalline Silicon Solar Panel Photovotaic Power Generation Module Household Street Lamp

Solar panels can be used for a wide variety of applications including remote power systems for cabins, telecommunications
equipment, remote sensing, and of course for the production of electricity by residential and commercial solar electric systems.

Use solar energy to power your home and reduce your dependence on the grid



96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor 3



5.  Package



Number of modules per pallet 30
Number of pallets per 40’ container 22

Packaging box dimensions

(L / W / H)

2135mm / 1110mm / 1190mm
Box weight 745 kg


96 Cell Mono 48.35v 500w Solar Panel High Efficiency Outdoor 4



6. Principles


A solar cell is a device that responds to light and can convert light energy into electricity. There are many kinds of materials that can produce photovoltaic effect, such as: single crystal silicon, polycrystalline silicon, amorphous silicon, gallium arsenide, indium copper selenide and so on. Their power generation principles are basically the same, and now take crystalline silicon as an example to describe the process of photovoltaic power generation. P-type crystalline silicon can be doped with phosphorus to obtain N-type silicon, forming a P-N junction.
