16.2kWh Stackable LiFePO4 Battery Residential Energy Storage Powerwall Pack

Name: 16.2kWh Stackable LiFePO4 Battery Residential Energy Storage Powerwall Pack
Brand: PVkingdom (Chongqing) New Energy Co., Ltd.
SKU: U Series 16.2kwh
Price: 0.12 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Goodwe

Certification: CE/RoHS/UN38.3/MSDS

Model Number: U Series 16.2kwh

Payment & Shipping Terms

Minimum Order Quantity: 10 units

Price: negotiable

Packaging Details: wooden Case

Delivery Time: 5-7 working days

Payment Terms: T/T

Supply Ability: 500 units/week

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                      16.2kWh Stackable LiFePO4, 16.2kWh Stackable LiFePO4 Battery, 16.2kWh Stackable LiFePO4 Powerwall


Name:	Stackable LiFePO4 Battery 16.2kwh	Nominal Voltage:	24V/25.6V 48V/51.2V
Communication Port:	CAN, RS485	Output Power Range:	3-50kwh
Grid Connection:	Off Grid, Hybrid Grid	Application:	Home Appliances, BOATS, Solar Energy System..
Cycle Life:	Over 6000 Times	Warranty:	5-10 Years
Type:	All-in-one	OEM/ODM:	Accepatable

Name:	Stackable LiFePO4 Battery 16.2kwh
Nominal Voltage:	24V/25.6V 48V/51.2V
Communication Port:	CAN, RS485
Output Power Range:	3-50kwh
Grid Connection:	Off Grid, Hybrid Grid
Application:	Home Appliances, BOATS, Solar Energy System..
Cycle Life:	Over 6000 Times
Warranty:	5-10 Years
Type:	All-in-one
OEM/ODM:	Accepatable

Description

16.2kWh Stackable LiFePO4 Battery Residential Energy Storage Powerwall Pack

Goodwe Lynx Home U Series 16.2kWh Low voltage battery Stackable LiFePO4 Battery Residential Energy Storage

Rated Energy (kWh)^*1		5.4	10.8	16.2	21.6	27.0	32.4
Usable Energy (kWh)^*2		4.8	9.6	14.4	19.2	24.0	28.8
Cell Type		LFP (LiFePO4)
Nominal Voltage (V)		51.2
Operating Voltage Range (V)		48 ~ 57.6
Nominal Dis- / Charge Current (A)^*3		50	100	100	100	100	100
Nominal Power (kW)^*3		2.88	5.76	5.76	5.76	5.76	5.76
Communication		CAN
Weight (kg)		57	114	171	228	285	342
Dimensions (W × H × D mm)		505 × 570 × 175 (LX U5.4-L)
Operating Temperature Range (°C)		Charge: 0 ~ +50 / Discharge: -10 ~ +50
Relative Humidity		0 ~ 95%
Max. Operating Altitude (m)		2000
Ingress Protection Rating		IP65
Mounting Method		Wall Mounted / Grounded
Standard and Certification	Safety	IEC62619, IEC62040, CEC
	EMC	CE, RCM
	Transportation	UN38.3

16.2kWh Stackable LiFePO4 Battery Residential Energy Storage Powerwall Pack
