Aluminium Single / Dual Axis Solar Module Mounting System Sun Tracking Series

Aluminium Single/Dual Axis Solar Module Mounting System Sun-Tracking Series

Product Descriptions:

By controlling the drive system, the control system tracks the sun based on the latitude, longitude and local time values downloaded from the GPS device to keep the solar panels at the most suitable angle for sunlight, thus maximizing the use of sunlight.

Single Axis Solar Tracker

These systems track the sun's movement along a single axis, typically from east to west. They can be either horizontal or tilted. Horizontal single-axis trackers rotate the PV panels around a horizontal axis, while tilted single-axis trackers adjust the tilt angle of the panels throughout the day. By tracking the position of the sun, the combined power output of a PV plant can be increased by 10-25 percent.

Dual Axis Solar Tracker

Dual-axis tracking systems are more advanced and track the sun's movement along both horizontal and vertical axes. They allow for precise tracking throughout the day, capturing maximum sunlight by following the sun's azimuth and elevation angles. By tracking the position of the sun in the north-south and east-west directions, the combined power output of a PV plant can be increased by  25%-40%

In terms of economics, single-axis tracking systems are generally more cost-effective compared to dual-axis tracking systems.

Regarding power generation efficiency, dual-axis tracking systems typically offer the highest efficiency.

In practical applications, an economic assessment and energy yield analysis need to be conducted to determine the most suitable installation structure for your needs. This assessment may involve considering factors such as budget, available space, geographical location, electricity prices, and available subsidies.

Details:

Key features:

• Top quality with competitive price---one of the biggest aluminum solar mounting manufacturer with integrated production in Xiamen.
• Full anodize for all components---offering 12 year warranty and 25 year life time.
• Excellent design ability---over 20 structure engineers, the chief engineer has 10 years' experience of structure engineering for aluminum solar mounting systems.
• Pre-assembly before shipping out, which saves about 30% installation time.

Production process
