Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01

Name: Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01
Brand: Kingfeels
SKU: KF-HK-BA01
Rating: 5 (125 reviews)

Product Details

Place of Origin: Xiamen, China

Brand Name: Kingfeels

Certification: CE

Model Number: KF-HK-BA01

Payment & Shipping Terms

Minimum Order Quantity: USD 20,000.00

Price: Negotiable

Packaging Details: Export package

Delivery Time: Within 15 days after receipt of payment

Payment Terms: T/T, L/C

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Roof Series KF-HK-BA01, Solar Module Mounting KF-HK-BA01, Solar Module Mounting System KF-HK-BA01


Install Site:	Ballasted Tilt Rooftops	Material:	Aluminium, Steel, AL6005-T5, SUS304
Max Wind Speed:	≤60m/s	Snow Load:	≤1.4KN/M2
Tilt Angle:	Adjustable	Adjustable:	AS/NZS 1170, ASCE 7-10, JIS2017
Color:	Silver	Warranty:	12 Years

Install Site:	Ballasted Tilt Rooftops
Material:	Aluminium, Steel, AL6005-T5, SUS304
Max Wind Speed:	≤60m/s
Snow Load:	≤1.4KN/M2
Tilt Angle:	Adjustable
Adjustable:	AS/NZS 1170, ASCE 7-10, JIS2017
Color:	Silver
Warranty:	12 Years

Description

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01

Product Descriptions:

The ballasted solar Module Mounting systems can be pre-designed a fixed angle for your request and the support is high Pre-assembled, especially, this system highlights the function that fixed directly on the concrete block. The special extruded aluminum rail, the tilt-in module, the clamp kit and the round leg can be high pre-assembly and make the installation easy and quick to save yourlabor cost and time.

Key Features:

Ballasted Solar Module Mounting Structures highly engineered solution which can effectively reduce the influence of wind on the photovoltaic system
Ballasted solar Module Mounting systems can secure the array without damaging the flat roof. Solar Ballast System is compatible with the usual framed modules and typically does not require roof penetrations.
Flat Roof Ballast Solar Module Mounting Structure designed according to the actual installation angle and no need to break the waterproof layer.

Details:

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01 0

Installation:

4. Fix the Crossbar 5. Install the Solar Panels 6. Component Details

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01 7

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01 8

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01 9

Design standard: JISC8955:2017/GB50009-2012/IBC2009/CBC2010/AS/NZS117

Production process

Ballasted Aluminium Solar Module Mounting System Roof Series KF-HK-BA01 10
